Description
Phase 1-Phase
Maximum PV Input Power 8500 W
Rated Output Power 6500 W
Maximum Solar Charging Current 160 A
GRID TIE OPERATION
PV INPUT ( DC )
Nominal DC Voltage/Maximum DC Voltage 360 VDC/500 VDC
Start-up Voltage/Initial Feeding Voltage 90 VDC/120 VDC
Maximum DC Voltage 90~450 VDC
Number of MPPT Trackers/Maximum Input Current 27A
GRID OUTPUT ( AC )
Nominal Output Voltage 220/230/240 VAC
Output Voltage Range 195.5-253 VAC
Nominal Output Current 29A
Power Factor >0.99
Feed-in Grid Frequency Range 49~51?Hz
EFFICIENCY
Maximum Conversion Efficiency( Soar to AC) 98%
TWO LOAD OUTPUT POWER(V2.0)
Full Load 6500 W
Maximum Main Load 6500 W
Maximum Second Load(battery mode) 2160 W
Main Load Cut Off Voltage 44 VDC
Main Load Return Voltage 54 VDC
OFF-GRID OPERATION
AC Input
AC Start-up Voltage/Auto Restart Voltage 120-140 VAC/180 VAC
Acceptable Input Voltage Range 90-280 VAC or 170-280 VAC
Maximum AC Input Current 40A
Nominal operating frequency 50/60Hz
Surge power 13000W
BATTERY MODE OUTPUT ( AC )
Nominal Output Voltage 220/230/240 VAC
Output Waveform PURE SINE WAVE
Efficiency(DC to AC) 94%
BATTERY & CHARGER
Nominal DC Voltage 48 VDC
Maximum Charging Current (Solar to AC) 160A
Maximum AC Charging Current 100A
GENERAL
PHYSICAL
Dimension,D x W X H(mm) 420*310*110
Net Weight(kgs) 11
INTERFACE
Communication Port RS232/WI-FI/GPRS
ENVIRONMENT
Operating Temperature -10~50?C
